FALCON TURBOS upgraded turbo based on genuine Garrett GTB2260VK 758351 765985 turbocharger, assembled using upgraded bearing system, billet compressor wheel and inconel high flow shaft-wheel. Ultimate Plug & Play solution for BMW 525D 530D 730D X5 X6 E-series M57TU2 engine.
We offer two versions of this turbocharger:
STAGE2 GTB2362VK (Efficiency) – Designed for daily driving with improved bottom-end responsiveness, top end power and long term durability. Does not require any hardware modifications.
62mm billet compressor wheel with extended tip
GTB23 High-flow shaft
Brand new “HELLA” actuator
Genuine Garrett Ball bearing system
Step-gap high temperature oil seals
Balanced and dynamically flow tested on CIMAT TURBO TEST EXPERT
Rated for 370+HP
STAGE3 GTB2872VK (Performance) – Design for motorsport applications for maximizing OM642LS engine potential. Would require modifications to fuel, air & exhaust systems.
72mm billet compressor wheel with extended tip
GTB28 High-flow shaft
Brand new “HELLA” actuator
Genuine Garrett Ball bearing system
Step-gap high temperature oil seals
Balanced and dynamically flow tested on CIMAT TURBO TEST EXPERT
Rated for 420+HP
STAGE4 FTD3279BB (Motorsport) – Ball bearing turbo with custom high flow housings. Only suitable for off road use. Would require modifications to fuel, air & exhaust systems.
79mm billet compressor wheel with extended tip
GT32 High-flow shaft
Brand new “HELLA” actuator
Genuine Borg-Warner EFR Ball bearing system
Upgraded VNT system
Step-gap high temperature oil seals
Balanced and dynamically flow tested on CIMAT TURBO TEST EXPERT
Rated for 480+HP
Fits turbos with following numbers:
758351-5024S
758351-9024S
758351-5022S
758351-5020S
758351-0020
758351-0019
758351-0017
758351-0015
765985-0001
765985-0003
765985-0005
765985-0006
765985-0008
765985-0010
765985-5001S
765985-5003S
765985-5005S
765985-5006S
765985-5008S
765985-5010S
11657794260
11652414328
7794259H
7794260014
A7794259H
A7794260014
7794260
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | May 2005 to March 2007 | M57N2 | 170kw / 231HP | 758351-5024S | 11657794260 |
| 2926 ccm | Mar 2007 to Sep 2010 | M57D30UL | 145kw / 197HP | 758351-5024S | 11657794260 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | Jan 2005 to Mar 2007 | M57N2 | 170kw / 231HP | 758351-5024S | 11657794260 |
| 2926 ccm | from March 2007 | M57N2 | 173kw / 235HP | 758351-5024S | 11657794260 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | Jan 2005 to Mar 2007 | M57N2 | 170kw / 231HP | 758351-5024S | 11657794260 |
| 2926 ccm | from March 2007 | M57N2 | 173kw / 235HP | 758351-5024S | 11657794260 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | Jan 2005 to Mar 2007 | M57N2 | 170kw / 231HP | 758351-5024S | 11657794260 |
| 2926 ccm | from March 2007 | M57N2 | 173kw / 235HP | 758351-5024S | 11657794260 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | Jan 2005 to Mar 2007 | M57N2 | 170kw / 231HP | 758351-5024S | 11657794260 |
| 2926 ccm | from March 2007 | M57N2 | 173kw / 235HP | 758351-5024S | 11657794260 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | Jan 2005 to Mar 2007 | M57N2 | 170kw / 231HP | 758351-5024S | 11657794260 |
| 2926 ccm | from March 2007 | M57N2 | 173kw / 235HP | 758351-5024S | 11657794260 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | from March 2007 | M57N2 | 170kw / 231HP | 765985-0006 | 7796314I09 |
| Engine | Years | Engine code | Power (kw / HP) | Part number | OE number |
|---|---|---|---|---|---|
| 2926 ccm | from March 2007 | M57N2 | 175kw / 235HP | 765985-0006 | 7796314I09 |
